防爆电梯是一种专门设计用于存在易燃易爆气体、粉尘等危险环境的特殊电梯,具有防爆、防火、防静电等安全特性,广泛应用于石油、化工、制药、军工、矿井等高风险场所。
参数
| Standard product | Customer-specific |
Model | SC 50-ISH | SC 100-ISH | SC 200-ISH | SC ***-ISH |
Load(kg) | 500 | 1000 | 2000 | 300~3000 |
speed(m/min) | 30 | 30 | 30 | 0~90 |
Max.install height(m) | 250 | 250 | 250 | 550 |
Car size(m) | 1.2*1.0 | 1.7*1.3 | 2.5*1.5 | Max. 3.2*1.5 |
Motor Power(kw) | 13 | 2*11 | 2*15 |
|
Mast | 450*450,650*200,650*650 |
|
Standards and regulations | EN 12159-2012,EN 81-20,EN 81-43 |
Applicable temperature | Max. -40~+50℃ |
Three-Part protocol | Conforms to local communication protocols |
Intelligent driving | Automatic leveling and floor operation system |
Optional anti-explosion | Max. ATEX/IEC EX Ⅱ CT4 |
